Freight shipping is required for Enclosures 9U and above. Please call us at 951-824-1571 for shipping details.

Cage nuts and rack screws are required for installation of patch panels and other components.

Description

Server Rack, Convex/Vented Doors

These are one of Kendall Howard's best looking LINIER® enclosures. Our design is packed with some of the most popular rack features for a price virtually anyone can afford. Built with a 24" or 36" depth, these LINIER® Server Cabinets are suitable for network servers, battery backups, switching banks, and other larger network equipment. The cabinet features laser knockouts allowing you to install fans, while removable slots provide numerous cable routing options. When you need a low-cost solution loaded with features, the LINIER® brand delivers big!

Includes one locking convex door and one locking vented door
Removable locking side panels
24" & 36" Depth
Sizes available: 22U, 27U, 37U, 42U
1300 lb. weight capacity (Holds 800 lbs. on casters)
Includes preinstalled casters and levelers
Includes two sets of adjustable cage nut style mounting rails
Top includes removable laser knockouts
19" EIA 310-D compliant
Made in the USA
5-Year Limited Warranty

Features

Features

Easy Installation - Casters and levelers are preinstalled to allow you to easily move and load your system into the desired location. (Rack hardware not included.)
Removable Cable Access Panels - The top of the server cabinet includes removable laser knockouts for cable access and added versatility.
Locking, Removable Side Panels - For a completely different look, the side panels are both removable and lockable giving you the option to create the cabinet that best suits your needs.
Adjustable Rails - Includes two sets of adjustable, vertical rails which extend to a maximum depth of 24" or 36" for versatile mounting options.
Secured System - Both doors are equipped with locks to help protect and secure your valuable equipment.
Locking Convex Door - The locking convex door provides a unique curb appeal for your cabinet, while remaining a cost-efficient solution for your equipment. This design also helps promote better air circulation within the cabinet, and is especially helpful when storing equipment that generates a lot of heat.
Locking Vented Door - The locking perforated door promotes better air circulation within the cabinet. This vented design is especially helpful for equipment that generates a lot of heat, such as servers, UPS's, and more.

Specifications

Specifications

Width	24"
Depth	27.5" (Usable Depth: 24") or 38.22" (Usable Depth: 36")
Height	45.50"(22U), 54.25"(27U), 71.75"(37U), 80.50"(42U)
Weight	24" Racks - 137 lbs.(22U), 145 lbs.(27U), 170 lbs.(37U), 185 lbs.(42U) 36" Racks - 148 lbs.(22U), 170 lbs.(27U), 198 lbs.(37U), 211 lbs.(42U)
Material(s)	CRS (Cold Rolled Steel)
Color/Finish	Medium Texture Black

Additional Information

Additional Information

Free Standing Server Cabinets Accessories

Server cabinets are an excellent means of providing both physical and environmental protection for your network equipment. We offer free standing server cabinets with either a vented or tempered glass door. We offer the LINIER® line of free standing server cabinets by Kendall Howard suitable for server storage, battery backups, and switching banks.

To learn more about our Free-Standing Enclosure Racks please visit our overview page. Kendall Howard's Server Enclosures can be combined with a wide array of products such as:

What's in the box?

What's in the box?

Qty 1 - LINIER® Server Cabinet - Convex/Vented Doors
