SFP Fiber Transceiver Module, 100BASE-LX, 1310nm SMF, up to 10KM DDM, LC, Cisco Compatible

The industry-standard Small Form-Factor Pluggable (SFP) Gigabit Interface Converter is a hot-swappable input/output device that plugs into a Gigabit Ethernet port or slot, linking the port with the network. SFPs can be used and interchanged on a wide variety of media converters and ethernet switches.

The 100BASE-LX SFP, compatible with the IEEE 802.3z 100BASE-LX standard, operates on standard single-mode fiber-optic link spans of up to 10KM and up to 550M on any multimode fibers. When used over legacy multimode fiber type, the transmitter should be coupled through a mode conditioning patch cable.

Specifications

Mode: Single-Mode Fiber (SMF)

Data-rate: 100BASE

Form-factor: SFP

Connector: LC

Wavelength: 1310nm

Distance (9um): 10km (6.2miles)

Cisco Compatibility Chart

Catalyst Express 500 Series

WS-CE500-24LC
WS-CE500-24PC
WS-CE500G-12TC
WS-CE520-8PC-K9
WS-CE520-24LC-K9
WS-CE520-24PC-K9
WS-CE520G-24TC-K9

Metro Ethernet

ME-2400-24TS-A
ME-2400-24TS-D
ME-3400-24TS-A
ME-3400-24TS-D
ME-3400G-12CS-A
ME-3400G-12CS-D
ME-3400G-2CS-A
ME-3400-24FS-A
ME-3400E-24TS-M
ME-3400EG-2CS-A
ME-3400EG-12CS-M
ME-C3750-24TE-M
ME-3600X-24FS-M¹
ME-3600X-24FS-M²
ME-3600X-24TS-M²
ME-3600X-24CX-M
ME-3800X-24FS-M³
ME-3800X-24FS-M²
ME-4924-10GE
ME-C6524GS-8S
ME-C6524GT-8S

Catalyst 2900 Series

WS-C2948G-GE-TX
WS-C2940-8TF-S
WS-C2950ST-8 LRE
WS-C2950ST-24 LRE
WS-C2950ST-24 LRE997
WS-C2960-24TC-L
WS-C2960G-24TC-L
WS-C2960-48TC-L
WS-C2960-24PC-L
WS-C2960-24TC-S
WS-C2960-48TC-S
WS-C2960-8TC-S
WS-C2960-48PST-L
WS-C2960-8TC-L
WS-C2960G-8TC-L
WS-C2960G-48TC-L
WS-C2960-48PST-S
WS-C2960-24PC-S
WS-C2960-24LC-S
WS-C2960+48PST-L
WS-C2960+24PC-L
WS-C2960+24LC-L
WS-C2960+48TC-L
WS-C2960+24TC-L
WS-C2960+48PST-S
WS-C2960+24PC-S
WS-C2960+24LC-S
WS-C2960+48TC-S
WS-C2960+24TC-S
WS-C2960S-24TS-S
WS-C2960S-48TS-S
WS-C2960S-48FPS-L
WS-C2960S-48LPS-L
WS-C2960S-24PS-L
WS-C2960S-48TS-L
WS-C2960S-24TS-L
WS-C2960S-48FPD-L
WS-C2960S-48LPD-L
WS-C2960S-24PD-L
WS-C2960S-48TD-L
WS-C2960S-24TD-L
2960S-F48TS-S
2960S-F24TS-S
2960S-F48FPS-L
2960S-F48LPS-L
2960S-F24PS-L
2960S-F48TS-L
2960S-F24TS-L
WS-C2960CG-8TC-L
WS-C2960C-8TC-S
WS-C2960C-8TC-L
WS-C2960C-8PC-L
WS-C2960C-12PC-L
WS-C2960X-24TS-LL
WS-C2960X-48TS-LL
WS-C2960X-24PSQ-L
WS-C2960X-24PS-L
WS-C2960X-24TS-L
WS-C2960X-48TS-L
WS-C2960X-48LPS-L
WS-C2960X-48FPS-L
WS-C2960X-24TD-L
WS-C2960X-24PD-L
WS-C2960X-48TD-L
WS-C2960X-48LPD-L
WS-C2960X-48FPD-L
WS-C2960XR-24TS-I
WS-C2960XR-48TS-I
WS-C2960XR-24PS-I
WS-C2960XR-48LPS-I
WS-C2960XR-48FPS-I
WS-C2960XR-24TD-I
WS-C2960XR-48TD-I
WS-C2960XR-24PD-I
WS-C2960XR-48LPD-I
WS-C2960XR-48FPD-I
WS-C2970G-24TS-E
WS-C2975GS-48PS-L

Catalyst 3500 Series

WS-C3560-24PS
WS-C3560-48PS
WS-C3560G-24TS
WS-C3560G-48TS
WS-C3560G-48PS
WS-C3560G-24PS
WS-C3560-48TS
WS-C3560-24TS
WS-C3560-8PC
WS-C3560-12PC-S
WS-C3560V2-24PS
WS-C3560V2-24TS
WS-C3560V2-48PS
WS-C3560V2-48TS
WS-C3560E-24TD⁵
WS-C3560E-24PD⁵
WS-C3560E-48TD⁵
WS-C3560E-48PD⁵
WS-C3560E-48PDF⁵
WS-C3560E-12D⁵
WS-C3560E-12SD
WS-C3560E-12SD⁵
WS-C3560X-24T⁶
WS-C3560X-48T⁶
WS-C3560X-24P⁶
WS-C3560X-48P⁶
WS-C3560X-48PF⁶
WS-C3560X-24T⁷
WS-C3560X-48T⁷
WS-C3560X-24P⁷
WS-C3560X-48P⁷
WS-C3560X-48PF⁷
WS-C3560CG-8TC-S
WS-C3560CG-8PC-S
WS-C3560C-8PC-S
WS-C3560C-12PC-S

Catalyst 3600 Series

WS-C3650-24TS
WS-C3650-48TS
WS-C3650-24PS
WS-C3650-48PS
WS-C3650-48FS
WS-C3650-24TD
WS-C3650-48TD
WS-C3650-24PD
WS-C3650-48PD
WS-C3650-48FD
WS-C3650-48FQ
WS-C3650-48PQ
WS-C3650-48TQ

Catalyst 3700 Series

WS-C3750G-12S
WS-C3750G-24TS
WS-C3750G-48TS
WS-C3750G-24PS
WS-C3750G-48PS
WS-C3750-24TS
WS-C3750-48TS
WS-C3750-24PS
WS-C3750-48PS
WS-C3750-24FS-S
WS-C3750-24WFS
WS-C3750V2-24PS⁴
WS-C3750V2-24TS⁴
WS-C3750V2-48PS⁴
WS-C3750V2-48TS⁴
WS-C3750V2-24FS⁴
WS-C3750E-24TD⁵
WS-C3750E-24PD⁵
WS-C3750E-48TD⁵
WS-C3750E-48PD⁵
WS-C3750E-48PDF⁵
WS-C3750X-24T⁶
WS-C3750X-48T⁶
WS-C3750X-24P⁶
WS-C3750X-48P⁶
WS-C3750X-48PF⁶
WS-C3750X-24T⁷
WS-C3750X-48T⁷
WS-C3750X-24P⁷
WS-C3750X-48P⁷
WS-C3750X-48PF⁷
WS-C3750X-12S⁸
WS-C3750X-24S⁸
WS-C3750X-12S⁹
WS-C3750X-24S⁹

Catalyst 3800 Series

C3850-NM-4-1G
C3850-NM-2-10G
C3850-NM-4-10G

Industrial Ethernet and Smart Grid

IE-2000-4TS-G-L
IE-2000-4TS-G-B
IE-2000-4T-G-L
IE-2000-4T-G-B
IE-2000-8TC-G-L
IE-2000-8TC-G-B
IE-2000-8TC-G-E
IE-2000-8TC-G-N
IE-2000-16TC-G-L
IE-2000-16TC-G-E
IE-2000-16TC-G-X
IE-2000-16TC-G-N
IE-2000-16PTC-G-L
IE-2000-16PTC-G-E
IE-2000-16PTC-G-NX

Catalyst 4500 Series

WS-X4013+TS
WS-X4013+10GE
WS-X4748-SFP-E
WS-X4724-SFP-E
WS-X4712-SFP-E
WS-X4448-GB-SFP
WS-X4506-GB-T
WS-X4516-10GE
WS-X45-SUP6-E¹⁰
WS-X4606-X2¹⁰
WS-X4624-SFP-E
WS-X45-SUP6L-E¹⁰
WS-X4612-SFP-E
WS-X4640-CSFP-E
WS-X4712-SFP+E
WS-X45-SUP7-E
WS-X45-SUP7L-E
WS-X45-SUP8-E
WS-C4500X-32SFP+
WS-C4500X-F-32SFP+
WS-C4500X-40X-ES
C4KX-NM-8SFP+
WS-C4500X-16SFP+
WS-C4500X-F-16SFP+
WS-C4500X-24X-ES

Catalyst 4900 Series

WS-C4948
WS-4928-10GE
WS-C4948E
WS-X4908¹¹

Catalyst 6500 Series

WS-SUP720
WS-SUP720-3B
WS-SUP720-3BXL
WS-SUP32-GE-3B
WS-SUP32-10GE-3B
WS-SUP32-GE-PISA
VS-S720-10G-3C
VS-S720-10G-3CXL
WS-X6724-SFP
WS-X6748-SFP
VS-S2T-10G
VS-S2T-10G-XL
WS-X6824-SFP-2T
WS-X6824-SFP-2TXL
WS-X6848-SFP-2T
WS-X6848-SFP-2TXL
WS-X6904-40G-2T
WS-X6904-40G-2TXL

Catalyst 6800 Series

C6880-X

Data Center and Blade Switching

2360-48TD-S
WS-CBS3020-HPQ
WS-CBS-3120G-S¹⁰
WS-CBS-3130G-S¹⁰
WS-CBS3032-DEL¹⁰
WS-CBS3110X-S¹⁰
N2K-C2232PP-10GE
N3K-C3064PQ
N3K-C3064PQ-10GE
N3K-C3048TP-1GE
N4K-4001I-XPX
N5K-C5010P-BF
N5K-C5020P-BF
N5K-C5548P-FA
N5K-C5548UP-FA
N5KC5596UP-FA
N55-M16P
N55-M8P8FP
N55-M16UP
N10-S6100
N10-S6200
N10-E0440
N10-E0600
N20-I6584
UCS-FI-6248UP
UCS-FI-E16UP
UCS-IOM-2208XP
N7K-M148GS-11
N7K-M148GS-11L
N7K-F132XP-15
N7K-F248XP-25
N7K-F248XP-25E
N77-F348XP-23
N9K-X9564PX
N9K-X9464PX
CSS11506-2AC
CSS11506-2DC
CSS11503-AC
CSS11503-DC
CSS11501
CSS5-SCM-2GE
CSS5-IOM-2GE

Routers

CISCO892F-K9
CISCO892FW-K9
HWIC-1GE-SFP
EHWIC-1GE-SFP-CU
NME-XD-24ES-1S-P
NME-XD-48ES-2S-P
Cisco 2921
Cisco 2951
SM-D-ES3G-48-P
SM-D-ES3-48-P
SM-D-ES2-48
Cisco 3825
Cisco 3845
Cisco 3925
Cisco 3945
Cisco 4451-X
CISCO7301
7304-NPE-G100
7300-NSE-150
WS-SUP720
WS-SUP720-3B
WS-SUP720-3BXL
WS-SUP32-GE-3B
WS-X6724-SFP
WS-X6748-SFP
RSP720-3C-GE
RSP720-3CXL-GE
RSP720-10GE
10x1GE-SFP-LC-B
4GE-SFP-LC
EPA-3GE-SX/LH-LC
CRS-16-RP
CRS-16-RP-B
CRS-FCC-SC-22GE
CRS-8-PRP-6G
CRS-8-PRP-12G
A901-12C-F-D
A901-12-C-FT-D
A901-4C-F-D
A901-4-C-FT-D
A901-6CZ-F-D
A901-6-CZ-FT-D
A901-6CZ-F-A
A901-6-CZ-FT-A
A9K-MPA-20X1GE

Appliances

SSM-4GE
NAM2204-SFP

LAN Controllers

AIR-CT5760-25-K9
AIR-CT5760-50-K9
AIR-CT5760-100-K9
AIR-CT5760-250-K9
AIR-CT5760-500-K9
AIR-CT5760-1K-K9
AIR-CT5760-HA-K9

¹ SFP ports
² SFP+ ports
³ Client ports
⁴ Uplink ports
⁵ With CVR-X2-SFP (for X2 ports)
⁶ With C3KX-NM-1G and C3KX-NM-10G (slots 1 and 3) network modules
⁷ With C3KX-NM-10G (slots 2 and 4) and C3KX-SM-10G network modules
⁸ Client ports and uplink ports with C3KX-NM-1G and C3KX-NM-10G (slots 1 and 3) network modules
⁹ Uplink ports with C3KX-NM-10G (slots 2 and 4) and C3KX-SM-10G network modules
¹⁰ With CVR-X2-SFP Twin Gig converter
¹¹ With CVR-X2-SFP Twin Gig converter in a WS-C4900M
