Wall Mounted, Plastic Fiber Distribution Unit

Holds 8 Adapters/Couplers with SC Simplex Footprint
Up to 12 Splices

The FB46-7280W8 is a new generation product for fiber to the home. This box is light and compact and is specially designed for connecting and protecting fiber cables. Applications: FTTH, FTTB, FTTP, FTTC, Telecommunication Network, CATV, Local Area Network.

Features

Suitable for wall-mounting installation
Suitable for 8 SC adapters
Easily access the interior with sliding shackles
Applicable for outdoor cables or indoor soft cables
Size: 199mm x 160mm x 46mm
The maximum capacity is 12 fibers
IP65 Rated

Specifications

Capacity

Splices: (12) splices
Adapters: (8) SC Simplex Sold Separately
or (8) LC Duplex with SC Simplex Footprint Sold Separately

Dimensions

Depth: 1.8"
Height: 7.8"
Width: 6.3"

Physical Properties

Material: Plastic
Color: Off White
