100GBase QSFP+to 4 x SFP28 Passive Copper Direct Attach Cable
The direct attach copper cables support 4 lanes of 25Gbs (100Gbs composite). This product is specifically designed to be fully compatible and functional with its brand's own designated switching devices. The passive design has no signal amplification. The passive QSFP28 to 4x SFP28 cable is a low cost alternative for short reach application.
Features
Features
- 4 independent duplex 10Gbs channels
- Supports 2.5Gbs and 5Gbs data rates
- AC-coupled inputs and outputs
- 100 Ohm differential impedance
- Metal housing for superior EMI performance
- Single power supply 3.3V
- Operating Temperature Range: 0°C to +70°C
Compliance
- QSFP+ MSA
- SFP+ MSA
- RoHS Compliant
Applications
- 10Gbase Ethernet
- Serial Data Transmission
- Networking, Storage, Fiber Channel
Specifications
Specifications
| Connector Type | QSFP28 to 4x SFP28 |
| Max Data Rate | 100GB |
| Wire AWG | 30 AWG Twinax |
| Cable Type | Passive |
| Power Supply | 3.3v |
| Operational Temperature Range | 0°C to +70°C |
