Fiber Optic FAST Connector, LC, Pre-Polished APC, Singlemode 9/125, 6 Pack

Fiber Optic FAST Connector, LC, Pre-Polished APC, Singlemode 9/125, 6 Pack

AFL

SKU:FAST-LC-SMAU-6


Regular price Price: $36.24
Regular price 83.99 Sale price Price: $36.24
*Shipping calculated at checkout
Sale Sold out
View full details

These products are all Made to Order

Which means they are non-cancelable and non-refundable

Description

Fiber Optic FAST Connector, Pre-Polished APC

FASTConnect™ field-installable connectors are factory pre-polished connectors that completely eliminate the need for hand polishing in the field. Proven mechanical splice technology ensuring precision fiber alignment, a factory pre-cleaved fiber stub, and a proprietary index-matching gel combine to offer an immediate low-loss termination to either single mode or multimode optical fibers.

FASTConnect™ connectors are compatible with 250um and 900um optical fibers, as well as 900um, 2mm, and 3mm cordage. All primary fiber types are supported, and each connector is color-coded per industry-standard requirements to aid in identification during and after installation. A factory-installed wedge clip (included with each connector) is removed and discarded upon completion of the termination. Incorporated into this device is an innovative, translucent wedge enabling the use of a common VFL to provide a "pass/fail" signal once physical contact is achieved.

900um boots are included and we also offer 2mm fiber boots and 3mm fiber boots that are sold separately.

Features

Features

  • Pre-stubbed, factory-polished ferrule
  • No epoxy required
  • Precision mechanical alignment ensures low-loss
  • Fiber can be reseated
  • 900um boot provided with each connector. 2mm and 3mm boots are also available separately.
  • VFI can be used to confirm fiber is installed properly
  • Meets TIA/EIA 568A performance requirements
  • Meets TIA/EIA 604 (focus) connector interface requirements

Applications

Applications

  • Premise environments
  • Connections at the desk for LAN environments
  • Patch panels
  • Direct equipment termination
  • Fiber to the Subscriber (FTTx) applications
  • Repair and replacement requirements
  • Equipment test leads

Specifications

Specifications

Additional Information

Additional Information

FAST Connector LC 900um Installation
