Fixed Wall Mount Racks

Fixed Wall Mount Racks

Fiber Savvy

SKU:NPNB-VW5-5081


Size
Regular price Price: $120.00
Regular price Sale price Price: $120.00
*Shipping calculated at checkout
Sale Sold out
View full details

Description

Fixed Wall Mount Racks

Our Wall Mount Racks are a cost-effective solution for storing rackmount IT equipment in environments that don’t require a lockable cabinet. The open frame design provides easy access to equipment and is shipped unassembled and flat packed for easy handling and reduced freight cost.

Features

Features

  • EIA-compliant 19” mounting rails with 10-32 tapped holes and printed RU markings
  • Provides 18” of equipment depth
  • Supports up to 150 lbs. of equipment (see Specifications for specific weight capacities)
  • Available in 8U, 15U, and 30U


Specifications

Specifications

Material
14 Gauge Cold Rolled Steel (Top & Bottom)
16 Gauge Cold Rolled Steel (Mounting Rails)
Compliance & Standards ANSI / EIA RS-310D, WIEC60297-2

Description Height Weight Capacity
NPNB-VW5-5081 8U Wall Mount Rack 17.75" 18.25 lbs 150 lbs
NPNB-VW5-5151 15U Wall Mount Rack
30.00" 22.00 lbs 150 lbs
NPNB-VW5-5301 30U Wall Mount Rack 56.24" 28.55 lbs 125 lbs

8U Fixed Wall Mount Rack

15U Fixed Wall Mount Rack

30U Fixed Wall Mount Rack



What's in the box?

What's in the box?

  • Qty 1 - Package of Fixed Wall Mount Rack
