Description
View 8+ Premium Core-alignment Splicer with Wi-Fi
The new premium core-alignment fusion splicer View8+ is the most powerful and innovative product to satisfy the demanding professionals who always demand for the highest performances on the go. View8+ features world class splice time of 6 seconds and heating time of 9 seconds with large battery capacity allowing 355 cycles. Together with 5 inch wide HD LCD monitor and user-friendly intuitive GUI (Graphic User Interface), this premium splicer comes with a dedicated Wi-Fi App which enhances practicality to check the work progress simply from a smartphone.
Features
Features
The Most Productivity Splicer Fast Splice Time 6 sec.
- Fast Heating Time 9 sec.
- Large Battery Capacity 355 cycles
- Automatic Arc Compensation
- 5 inches wide HD LCD monitor
- Wi-Fi
Specifications
| Specifications | |
|---|---|
| Model | View 8+ |
| Dimensions |
162mm H x 147mm W x 157mm D (including rubber bumper) |
| Weight |
2.12 KG (without battery) 2.78 KG (with battery) |
| Number of Fiber | Single |
| Applicable Fibers |
SM (ITU-T-G.652 & G.657) MM (ITU-T- G.651) DS (ITU-T-G.653) NZDS (ITU-T-G.655) |
| Cleaved Length | 8-16mm |
| Cladding Diameter | 80µm - 150µm |
| Splicing Mode | Max 128 modes, Preset 45 user modes |
| Heating Mode | Max 32 modes |
| Typical Splice Loss |
SM: 0.02dB MM: 0.01dB DS: 0.04dB NZDS: 0.04dB (ITU-T-standard) |
| Return Loss | >> 60 dB |
| Lighting | 2 White LEDs |
| Splicing Time |
Quick mode 6 sec SM mode 8 sec |
| Estimated Splice Loss | Available |
| Heating Sleeve Length | 20mm - 60mm |
| Heating Time | Quick mode 9 sec |
| Results Storage | The last 10,000 results |
| Tension Test | 1.96 - 2.25N |
| Operating Condition |
Altitude: 0 to 5000m above sea level Humidity: 0 -95% non dew Temperature: -10 - 50°C Wind: 15m/sec |
| Storage Condition |
Humidity: 0-95% non dew Temperature: -20~60℃ |
| Display |
5.0 inches HD color LCD display |
| Fiber View & Magnification |
320x Magnification Four Display modes |
| Power Supply | AC Input 100-240V, DC Input 19-3.42A |
| No. of Splice & Heating With Battery |
9000mAh Battery Capacity Typical 355 times (Splice + Heat) |
| Operating Methods | Button / Touch Screen |
| Automatic Calibration | Automatic arc calibration by air pressure and temperature |
| Electrode Life | 5500 arcs, can be extended by using an electrode grinder |
| Terminal | USB2.0/ Mini USB |
Additional Information
| Product Videos | |
|---|---|
VIEW 8+ SPLICE & HEATING WITH TIMECODE |
What's in the Box
What’s in the Box
- Qty 1 - INNO Instrument View 8+ Fusion Splicer
- Qty 1 - High Precision Cleaver (V10 or V7 PRO, model may vary)
- Qty 1 - Fiber Holder (FH-45)
- Qty 1 - AC Adapter
- Qty 1 - Battery Pack
- Qty 1 - Power Cable
- Qty 1 - Cooling Tray
- Qty 1 - Electrode Set
- Qty 1 - Carrying Case
- Qty 1 - User Manual
