Description
Cisco Compatible MPO/MTP® PSM4 40G QSFP+ Transceiver Module
This 40G QSFP+ (Quad Small Form-Factor Pluggable) PSM4 portfolio offers customers a wide variety of high-density and low-power 40 Gigabit Ethernet connectivity options for data center, high-performance computing networks, enterprise core and distribution layers, and service provider applications. This Transceiver has 4 independent Full-duplex channels with up to 10.3125Gbps data rate per channel. Transceiver can extend the transmission up to 10km using a single-mode fiber optic cable.
Features
Features
- 4 independent full-duplex channels up to 10.3125Gbps data rate per channel
- MTP®/MPO optical connector
- Digital diagnostic capabilities
- Capable up to 10km using a single-mode fiber optic cable
- Single +3.3V power supply
- Operating temperature of 0ºC ~ 70ºC
Additional Information
Standards & Compliance's
- Compliant with QSFP+ MSA Compliant
- RoHs Compliant
- XLPPI Electrical Interface Compliant with IEEE 802.3ba-2010
- Compliant with QSFP+ MSA: SFF-8436
- Support optical interoperability with IEEE 802.3ae 10GBASE-LR modules
Applications
- 40G Ethernet
- Infiniband 4x SDR DDR QDR
- 40G Telecom Connections
What's in the Box
What’s in the Box
- Qty 1 - QSFP+ PSM4 Transceiver Modules, 40Gb/s, MPO/MTP Fiber Optical Connector, Cisco Compatible, up to 10km
