Designed to detect fiber breakpoints, fiber leaks, poor connections, and stress points, this visual fault locator is perfect for field personnel detecting faults in fiber optic cables.
Features
Features
650 nm Class IIIA laser diode identifies faults in single and multi-mode fiber up to 3 miles long
Universal connector accommodates 2.5mm ferruled connectors, such as FC, SC, and ST connectors
Has three different modes: Continuous wave, pulsing, and slower pulsing mode
Works in OTDR dead zones and is used for end-to-end visual fiber identification
Light and portable pen-style design is perfect for on the go use
Use 60 hours of battery life powered by two AAA batteries (included)
Product has been independently tested to meet ETL Listed standards
Specifications
TECHNICAL SPECIFICATIONS
Fiber Connector
FC, SC, ST
Light Source
Class IIIA Laser Diode
Distance
Up to 5 km (3.10 miles)
Wavelength
650 nm
Working Temperature
-4 Fahrenheit (-20 Celsius) to 140 Fahrenheit (60 Celsius)
Storage Temperature
-40 Fahrenheit (-40 Celsius) to 185 Fahrenheit (85 Celsius)
Power
2 AAA Batteries
Battery Life
60 hours
Dimensions
9 in x 2 in x 1 in (22.86 cm x 5.08 cm x 2.54 cm)
Weight
0.34 lb (154.36 g)
UPC #
811490016026
Additional Information
Product Videos
VFL-25 VISUAL FAULT LOCATOR
What's In The Box
What's In The Box
Qty 1 - Visual Fault Locator
